Stencils play a crucial role in two-layer PCB manufacturing, ensuring accurate and efficient application of solder paste to the board. A two-layer PCB stencil is specifically designed to align with the board's surface, allowing for precise solder paste deposition on the designated pads. This process enhances production efficiency, reduces errors, and ensures strong, reliable solder joints.
