A PCB stencils is a thin metal sheet, typically made of stainless steel, used in the PCB assembly process. It features precise cutouts that match the solder pads on the PCB. The stencil is placed over the board to apply solder paste accurately onto the pads, ensuring proper component placement and soldering during the reflow process.
Sonia Singh
Liked Like Share

What is PCB Stencil?
